Aqua Control Select Series 2 Trillium Pond Fountain
Free Shipping To:
...
Order Now, Get It By:
Choose Motor Strength:
Choose Cord Length:
Free Shipping
For All Orders
No Sales Tax
In Most States
Easy Returns
Within 30 Days
Secure Checkout
SSL Encrypted
- Aqua Control Select Series 2 Trillium Pond Fountain
- Floating pond & lake fountain, great for commercial or residential use.
- Package includes: fountain pump, control panel timer, nozzle, float, filter screen and power cord.
- Ideal for ponds & lakes 1/4 acre or larger in size, 32" to 44" or more in depth.
- Powerful flow rates allow for high volume mixing and significant turnover.
- Available as 230V only. Three-phase available upon request.
- 3-Year Limited Warranty, made in Illinois.
- Included Control Panel
- Minimum NEMA 4X compact fiberglass outdoor enclosure. Padlock compatible.
- Through-the-door safety disconnect switch with lockout capability.
- Individual GFCI protection for motor & lights, built standard with 1 light circuit & ground connectors.
- Includes 24-hour pump & light timers.
- Wire ways for neat & safe wiring.
- Most components are DIN rail mounted for ease of service.
- Single phase panels include: capacitors, start circuit & re-settable overloads.
- Standard single-phase panels are UL listed.
- Optional Color Changing Light Kits
- Cool white, warm white, red, green, blue and amber colors.
- Includes a WiFi enabled control panel for easy operation.
- 3 or 4 fixture sets with quick disconnects. 3 fixtures are recommended for 1 HP fountains, 4 fixtures recommended for 2 HP & 3 HP fountains.
- Wide 90° flood beam angle standard.
- IP68 protection grading for waterproof underwater lighting.
- Voltage 50-60Hz AC 85-265V, 36W Per Fixture.
- Type 304 stainless-steel body.
- Motor Comparison
 |
 |
 |
 |
| 1 HP | 2 HP | 3 HP | |
| Spray Size | 9' H x 15' W | 12' H x 18' W | 16' H x 26' W |
| Best For Ponds | 1/4 - 3/4 Acre | 3/4 - 1 Acre | 1 - 2 Acre (+) |
| Minimum Depth | 32 Inches | 44 Inches | 44 Inches |
| Pump Flow Rate | 15,000 GPH | 21,000 GPH | 27,000 GPH |
| Amps - 230V | 10.0A / 230V | 13.0A / 230V | 17.0A / 230V |
| Operating Cost | $0.30 / Hour | $0.45 / Hour | $0.60 / Hour |
| Product Warranty | 3-Year Limited Warranty | 3-Year Limited Warranty | 3-Year Limited Warranty |
⚠️ Always use a GFCI and disconnect power when swimmers are present. Never use an extension cord to supply power to the motor. All wiring shall be completed by a licensed electrician and comply with NEC / local electrical codes. Operating costs are calculated based on the national average cost per kWh; actual costs may vary depending on your location.
